| CPU | MIPS 34Kc 720 MHz |
| Memory | RAM: 128MB, NAND Flash: 512MB |
| Real Time Clock | Lithium Battery Back Up, Data Retention Period 7 years |
| WAN Port | Gigabit Ethernet 1 port RJ45 x 1 |
| WAN/LAN Port | Gigabit Ethernet 1 port RJ45 x 1 |
| LAN Port | Gigabit Ethernet 1 port RJ45 x 1 |
| WiFi Standard | IEEE 802.11b/g/n |
| WiFi Security | WPA2 (CCMP), WPA-WPA2 (TKIP-CCMP), Basic (WEP64/128) |
| WiFi Throughput | 802.11b: 5-6Mbps / 802.11g: 20Mbps / 802.11n: 70-80Mbps |
| Firewall | Packet Filtering, Basic DoS Attack Prevention/Stateful Packet Inspection (SPI), DMZ Host |
| NAT/NAPT | Available |
| QoS | IEEE802.11e EDCA |
| Static Routing | Available |
| USB Port | USB 2.0 1 port Type-A connector x 1 |
| LED Indicators | System Status, Wi-Fi Setup Status, WAN, LAN/WAN, LAN status |
| Button | Wi-Fi Setup, INITIALIZE |
| Line Port (LCOT) | 4 Ports CO Line interface RJ11, Caller ID functions are supported |
| EXTN Port (SLC) | 8 Ports SLT interface RJ11, Caller ID functions are supported |
| Option Card Socket | 8 Ports SLC8/FXS8, 8 Ports LCOT4/FXO4, 2 Ports DPH2 |
| Power Input/Consumption | 110VAC to 127VAC/220 VAC to 240 VAC, 60W |
| External Battery Input | DC 12V |
| Regulatory | CISPR32/22 Class B / FCC Class B EMC |
| Installation Environment | Wall Mount, Horizontal (Desktop) Installation |
| Operating Temperature | 0° to +40°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Other Features | Air-Cooling Method: Built-in Fan |
| Dimension (WHD) | 297 x 210 x 90.4 mm |
| Weight | Approx. 2.2Kg |
| Alnect Care Warranty | 30 Hari |
| Standard Warranty | 1 Tahun |
| Manufacturer website | http://www.panasonic.com/ |
