CPU |
MIPS 34Kc 720 MHz |
Memory |
RAM: 128MB, NAND Flash: 512MB |
Real Time Clock |
Lithium Battery Back Up, Data Retention Period 7 years |
WAN Port |
Gigabit Ethernet 1 port RJ45 x 1 |
WAN/LAN Port |
Gigabit Ethernet 1 port RJ45 x 1 |
LAN Port |
Gigabit Ethernet 1 port RJ45 x 1 |
WiFi Standard |
IEEE 802.11b/g/n |
WiFi Security |
WPA2 (CCMP), WPA-WPA2 (TKIP-CCMP), Basic (WEP64/128) |
WiFi Throughput |
802.11b: 5-6Mbps / 802.11g: 20Mbps / 802.11n: 70-80Mbps |
Firewall |
Packet Filtering, Basic DoS Attack Prevention/Stateful Packet Inspection (SPI), DMZ Host |
NAT/NAPT |
Available |
QoS |
IEEE802.11e EDCA |
Static Routing |
Available |
USB Port |
USB 2.0 1 port Type-A connector x 1 |
LED Indicators |
System Status, Wi-Fi Setup Status, WAN, LAN/WAN, LAN status |
Button |
Wi-Fi Setup, INITIALIZE |
Line Port (LCOT) |
4 Ports CO Line interface RJ11, Caller ID functions are supported |
EXTN Port (SLC) |
8 Ports SLT interface RJ11, Caller ID functions are supported |
Option Card Socket |
8 Ports SLC8/FXS8, 8 Ports LCOT4/FXO4, 2 Ports DPH2 |
Power Input/Consumption |
110VAC to 127VAC/220 VAC to 240 VAC, 60W |
External Battery Input |
DC 12V |
Regulatory |
CISPR32/22 Class B / FCC Class B EMC |
Installation Environment |
Wall Mount, Horizontal (Desktop) Installation |
Operating Temperature |
0° to +40°C |
Operating Humidity |
10% to 90% (non-condensing) |
Other Features |
Air-Cooling Method: Built-in Fan |
Dimension (WHD) |
297 x 210 x 90.4 mm |
Weight |
Approx. 2.2Kg |
Alnect Care Warranty |
30 Hari |
Standard Warranty |
1 Tahun |
Manufacturer website |
http://www.panasonic.com/ |
